SPECIFICATIONS
8CH POE NVR: 8CH 4K / 8CH 5MP / 16CH 5MP
Alarm System: Motion Detection+Email Alert+APP Push
Alarm Type: Email Photo
Audio Compression Format: G711A
Audio Input: 1 RCA
Audio Output: 1CH RCA
Backup Type: Hard Drive
Brand Name: Techage
Certification: CE
Communication Interface: RS-485
Compression Format: H.265
Hard Drive Size: 3.5”
Hard drive Interface Type: SATA
High-concerned chemical: None
IP Mode: Static IP address
Mobile Phone Viewing: Yes via XMEYE APP
Model Number: TA-6708K
Network Interface: RJ45 10/100M
Network Protocol: DDNS,SMTP,TCP/IP
Origin: Mainland China
P2P Remote View: Support Android and iPhone(iOS)
POE: 8 Port
Power Supply: 8CH POE ,DC52V with US/EU/AU/UK Plug Available
Smart home platform: Other
Support Language: Multi language(English,Spanish,Russian etc.)
Supported Mobile Systems: Android,iPhone OS
Supported Operating Systems: Microsoft Windows XP,Microsoft Windows 7,Microsoft Windows 98,Microsoft Windows Vista,Microsoft Windows 2000
Technology: Network
Two-way Audio: Yes
Video Compression Format: H.265
Video Input Interface: RJ45
Video Output: 1VGA + 1HDMI-Compatible,VGA/HD Port
Video Resolution: 5 MP,6mp,960P,3 MP,4MP,720p,1080p
Video Standard: NTSC,PAL
Whether or Not 50Vac or 75Vdc or Higher Power Supply: No
Wireless Security: wep
e-Cloud(P2P): Yes
Note: The old version will be shipped from China. The new version will be shipped from overseas warehouses.
Sopport Ultra HD 4K Display
H.265 POE NVR
H.265 More Clear , HD resolution offer you best image qualityin a lower bit rate.
Save more storage space,can reduce 40%-50% file size,save your HDD storage space and reduce your purchase cost.
H.265 only need a lower bandwidth,speed loading faster,play video more smoothly
POE Advantage, Why Choose POE?
Don’t need extra power cables or adapters or switch.Plug And Play and easy setup.
Save Money and Convenient,POE NVR = NVR + POE Switch
Support be extended to 8CH/16CH NVR
Our 8CH POE NVR Can be Extended to 16pcs POE Camera if use 8CH POE Switch Together
4CH POE NVR Can be Extended to 8pcs POE Camera if use 4CH POE Switch Together
If you want to buy 4CH/8CH/16CH POE Switch, please click the picture
Techage POE CCTV System
Max support 100 meters transmission distance
Our NVR Supports up to 14TB HDD
Install and Connect it
It can be quickly and easily setup by anyone. Instantly see live video using your computer, tablet, or phone from anywhere.
Don’t need extra power cables or adapters or switch.
Support work with third-party cameras
Advanced Human Detection
The human detection function: when human is detected the NVR will save the footage into hard disk without missing any important events.
E-mail Alerts
NVR will send you mail automatically if there is any motion detected.
Video With Smart Playback
Smart playback available with customizable searching area, playback time is greatly reduced by speeding through unimportant videos.
Remote Access Anytime, Anywhere
Based on P2P (peer to peer) technology, support plug-and-play installation. Access the IP camera through its web interface via Internet Explorer, also comes with a free smartphone App (Android & iPhone) for remotely view from anywhere.
Support iOS and Android Device Access. Scan QR-Code to login. Download free app in Apple App store / Google play.
H.265 4K/8MP POE NVR(with Audio out)
H.265 8CH 4K/8MP
Support HD output VGA HD output
Support ; access third party
Support web, CMS, center platform management software MYEYE
Support multiple network services (support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL, IP searches, Alarm Center, etc.)
System resources :Simultaneous multi-channel real-time, playback, network operation, USB backup
Display quality :4K/5MP/4MP/1080P
Audio compression: G.711A
Mode: Manual>Alarm>Dynamic Detection>Timing
Storage: HDD
Backup mode : Network backup, USB hard disk, USB burner, SATA burner
Network interface:8CH POE Port, the standard POE IEEE802.3af/at Protocol
P2P Remote View: Support iOS, Android
20+ Languages Available: Russian, English, Italian, Portuguses, Spanish, French, German etc
8CH POE NVR can support 8CH 1080P / 8CH 5MP / 8CH 4K / 16CH 5MP
4CH POE NVR can support 4CH 1080P / 4CH 5MP / 4CH 4K / 8CH 5MP
1, 8CH POE NVR can support 4K/8MP max, you can connect 2MP,4MP,5MP,4K cameras with our NVR. but you need buy our 5MP/4K cameras , then they can work together !
2, If you want connect 16CH 5MP cameras , you buy to buy a extra 8CH POE Switch , please contact us buy it !
4CH POE NVR can support 4CH 5MP / 8CH 4MP
Package Included:
1 x4CH/8CH 4K POE NVR
1 X USB Mouse
1 xUser Manual
1 X Power Adapter for NVR
1 X Remote Control (No Battery)
Note :Our POE NVR include the remote control ( without battery )
